Is the DKR-F 90Â° hydraulic end, type ZBW240, carbon steel compatible with standard BSP-threaded hoses and a flat gasket for crimping?

Yes. The DKR-F 90Â° hydraulic end, type ZBW240, carbon steel is compatible with standard internal BSP-threaded hoses and uses flat sealing via an additional flat gasket. It is designed for crimping onto hydraulic and industrial hoses using a crimping sleeve appropriate for the hose type. Material is carbon steel, galvanized, and the fitting includes the internal BSP thread and nut; flat sealing requires the DKR-F flat gasket to ensure proper leak-free assembly.

Does the DKR-F 90Â° hydraulic end, type ZBW240, carbon steel require a specific flat gasket thickness for BSP internal thread installations?

No - the DKR-F 90Â° hydraulic end, type ZBW240, carbon steel does not require a specific flat gasket thickness specified in the provided description. It states that an additional flat gasket (DKR-F) is required for flat sealing with BSP internal thread and nut, but no particular thickness is mentioned. Use a gasket compatible with BSP flat sealing standards and the fitting/nut geometry; if a specific thickness is needed for your assembly or pressure rating, confirm with the manufacturer or reference applicable sealing standards.

Can the DKR-F 90Â° hydraulic end, type ZBW240, carbon steel be used with reusable crimping sleeves for industrial hoses?

Yes. The DKR-F 90Â° hydraulic end, type ZBW240, carbon steel is designed for crimping in hydraulic and industrial hoses using a crimping sleeve suitable for the hose type, so it can be used with reusable crimping sleeves provided the sleeve matches the hose and the fitting's crimp profile and dimensions. Key points to confirm before assembly: - Sleeve compatibility: use a reusable sleeve specifically rated for the hose construction (material, reinforcement, inner tube) and compatible with ZBW240 crimp dimensions. - Crimp method & tooling: ensure the crimping tool and jaw set are appropriate for reusable sleeves and the sleeve diameter required by the DKR-F 90Â° fitting. - Sealing: the ZBW240 uses an internal BSP thread with nut and flat sealing (DKR-F) and requires an additional flat gasket; ensure gasket and seating surfaces are correct and in good condition. - Pressure rating and certification: verify the assembled hose, sleeve, and fitting combination meets the required working pressure, safety factors, and any applicable standards or manufacturer recommendations. - Inspection and testing: perform visual inspection and pressure test per industry practice after assembly. If all compatibility, tooling, sealing, and pressure requirements are met, the DKR-F 90Â° hydraulic end, type ZBW240, carbon steel may be used with suitable reusable crimping sleeves.

Embout hydraulique DKR-F 90°, type ZBW240, acier au carbone

Informations complémentaires

Matériau	CS – acier (fonte)

Embout hydraulique standard (type Z – avec une « queue » hydraulique classique pour flexible), à filetage femelle BSP avec écrou, étanchéité plane – nécessite l’utilisation d’un joint plat supplémentaire (DKR-F), coudé 90°. Conçu pour le sertissage sur flexibles hydrauliques et industriels à l’aide d’une bague de sertissage adaptée au type de flexible. Matériau : acier au carbone, galvanisé.

Liste des variantes de produit

Référence article	Nom de la variante du produit	DN	BAR	Disponibilité	Actions
TI-ZBW240-04-04	Raccord terminal 90° femelle 1/4" BSP, tuyau 1/4", bout à bout	6	-	En stock	Demande
TI-ZBW240-06-04	Raccord terminal 90° femelle 3/8" BSP, tuyau 1/4", bout à bout	6	-	En stock	Demande
TI-ZBW240-06-06	Raccord terminal 90° femelle 3/8" BSP, tuyau 3/8", bout à bout	10	-	En stock	Demande
TI-ZBW240-08-08	Raccord terminal 90° femelle 1/2" BSP, tuyau 1/2", bout à bout	12	-	En stock	Demande
TI-ZBW240-10-10	Raccord terminal 90° femelle 5/8" BSP, tuyau 5/8", bout à bout	16	-	En stock	Demande
TI-ZBW240-12-12	Raccord terminal 90° femelle 3/4" BSP, tuyau 3/4", bout à bout	20	-	En stock	Demande
TI-ZBW240-16-16	Raccord terminal 90° femelle 1" BSP, tuyau 1", bout à bout	25	-	En stock	Demande
TI-ZBW240-20-20	Raccord terminal 90° femelle 1.1/4" BSP, tuyau 1.1/4", bout à bout	32	-	En stock	Demande
TI-ZBW240-24-20	Raccord terminal 90° femelle 1.1/2" BSP, tuyau 1.1/4", bout à bout	32	-	En stock	Demande

Vous avez besoin d'une plus grande quantité de produits ou d'un devis personnalisé ?

Appelez-nous : +33 679 352 568 ou envoyez-nous un e-mail : wirthjeanpierre@aol.fr

Envoyer une demande

Embout hydraulique standard (type Z – avec une « queue » hydraulique classique pour flexible), à filetage femelle BSP avec écrou, étanchéité plane – nécessite l’utilisation d’un joint plat supplémentaire (DKR-F), coudé 90°. Conçu pour le sertissage sur flexibles hydrauliques et industriels à l’aide d’une bague de sertissage adaptée au type de flexible. Matériau : acier au carbone, galvanisé.
